GHI-282


More Product Pictures
Download File

Specifications

Model: GHI-282
Max. Board Size: ATX (12" x 9.6")
System Board Type: Core i, Core2Duo, Core2Quad, Pentium, Dual Xeon, AMD 64, Dual Opteron, Athlon

  Product Information
Standard: EIA RS-310C 19" Rackmount Standard
Construction: Heavy Duty Cold Rolled Electroplated Steel
Color: Black (Standard), Beige or Custom
Drive Bays: 1x Slim CD-ROM & 1x Slim FDD & 8x 3.5" Swappable Trays & 2x 2.5"HDD
Power Supply: 2U Single up to 510W or Redundant up to 400W ATX P/S (Rear Installation) Max. Depth 240mm
Cooling Units: 4x (80mm = 42.5CFM ea.) Fan
Expansion Slot: 2 or 3x Horizontal ISA/PCI/AGP Option Slots(GHI-282) or 7x Low Profile PCI Slots(GHI-282V)
Connector Port (front): 2x USB Ports
Indicators:
Buttons: Power ON/OFF Momentary (Pushbutton), System Reset, Buzzer Reset
Crossbar:
Thermal Card: GHA-CO04
Front Door(s): Single Door With 2 Thumbscrews (Removable)
Air Filter:
Dimensions(W x H x D): 483 x 88 x 565mm (19" x 3.5" x 22.2")
Weight: 17.5kgs / 38.5lbs
Cu. ft.: 3.9
Carton Size: 58.8 x 25.5 x 74.5 (23.1" x 10" x 29.3")
Humidity: 5% - 95% Non-condensing
Product Applications:

  Optional Accessories
HDD Drive Accessories:
Slide Rails:
Chassis Height: 2U
