| Model: |
GHI-292 |
| Max. Board Size: |
Max. to 9.6" x 9.6" |
| System Board Type: |
Core i, Core2Duo, Core2Quad, Pentium, Dual Xeon, AMD 64, Dual Opteron, Athlon |
| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard), Beige or Custom |
| Drive Bays: |
1x Slim CD-ROM & 1x Slim FDD & 8x 3.5" Swappable Trays & 1x 2.5"HDD (SATA, SCSI320, Multilane SATA or SAS Drive Interface) |
| Power Supply: |
PS/2 Size Single or Mini Redundant up to 400W ATX P/S Max. Depth 200mm (optional) |
| Cooling Units: |
4x (80mm = 42.5CFM ea.) Fans |
| Expansion Slot: |
4x Low Profile PCI Slots |
| Connector Port (front): |
2x USB Ports |
| Indicators: |
|
| Buttons: |
Power ON/OFF, System Reset, Buzzer Reset |
| Crossbar: |
|
| Thermal Card: |
GHA-CO04 |
| Front Door(s): |
Single Door With 2 Thumbscrews (Removeable) |
| Air Filter: |
|
| Dimensions(W x H x D): |
483 x 88 x 535mm (19" x 3.5" x 21.1") |
| Weight: |
14.8 kgs / 32.6 lbs |
| Cu. ft.: |
3.6 |
| Carton Size: |
58.8 x 25.5 x 68.5 (23.1" x 10" x 27") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
NAS, File Server |
| HDD Drive Accessories: |
|
| Slide Rails: |
GHA-SL20, GHA-SL24 |
| Chassis Height: |
2U |
|
|
