| Model: |
GHI-405 |
| Max. Board Size: |
ATX (12" x 10.5") |
| System Board Type: |
Core i, Core2Duo, Core2Quad, Pentium, Dual Xeon, AMD 64, Dual Opteron, Athlon |
| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard), Beige or Custom |
| Drive Bays: |
1x 5.25" CD-ROM & 2x 3.5" HDD (Hidden) |
| Power Supply: |
PS/2 or Mini Redundant ATX P/S(Rear Installation) Max. Depth 200mm |
| Cooling Units: |
3x (80mm = 42.5CFM ea.) & 1x (120mm = 90CFM ea.) Fans |
| Expansion Slot: |
7 Slots |
| Connector Port (front): |
2x USB Ports |
| Indicators: |
|
| Buttons: |
Power ON/OFF, System Reset |
| Crossbar: |
|
| Thermal Card: |
|
| Front Door(s): |
Single Door With 2 Thumbscrews |
| Air Filter: |
|
| Dimensions(W x H x D): |
483 x 177 x 355mm (19" x 7" x 14") |
| Weight: |
12.1 kgs / 26.7 lbs |
| Cu. ft.: |
4 |
| Carton Size: |
60.5 x 34 x 54.5 (23.8" x 13.4" x 21.4") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
| HDD Drive Accessories: |
|
| Slide Rails: |
|
| Chassis Height: |
4U |
|
|
