| Model: |
GHI-419 |
| Max. Board Size: |
EATX (12" x 13") or (SR Version) GHP-2008, GHP-2208, GHP-2014, GHP-2214, GHP-P14P4, GHP-2214D |
| System Board Type: |
Core i, Core2Duo, Core2Quad, Pentium, Dual Xeon, AMD 64, Dual Opteron, Athlon or Passive Backplane (SR Version) |
| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard), Beige or Custom |
| Drive Bays: |
2x 5.25" & 1x 3.5" & 5x 3.5" HDD & 1x 3.5"HDD (Optional) |
| Power Supply: |
PS/2 Size Single up to 700W or Redundant up to 500W ATX P/S(Rear Installation)Max.Depth 300mm |
| Cooling Units: |
2x (90mm = 51CFM ea.) Fans & 2x (60mm = 23.5CFM ea.) Fans (Optional) |
| Expansion Slot: |
7 slots |
| Connector Port (front): |
2x USB |
| Indicators: |
|
| Buttons: |
Power ON/OFF Momentary (Pushbutton), System Reset |
| Crossbar: |
|
| Thermal Card: |
|
| Front Door(s): |
|
| Air Filter: |
|
| Dimensions(W x H x D): |
483 x 177 x 510mm (19" x 7.0" x 20.1") |
| Weight: |
17.8kgs / 39.3lbs |
| Cu. ft.: |
4.9 |
| Carton Size: |
68.8 x 34.0 x 59.1 (27.1" x 13.4" x 23.3") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
| HDD Drive Accessories: |
|
| Slide Rails: |
|
| Chassis Height: |
4U |
|
|
GHI-419.pdf
