| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard) or Custom |
| Drive Bays: |
2x 3.5"HDD & 1xSlim FDD & 1xSlim ODD |
| Power Supply: |
PS/2 Size Single or Mini Redundant ATX PSU (Rear Installation) Max. Depth 200mm |
| Cooling Units: |
4x (92mm = 51CFM ea.) Hot Swap Fans |
| Expansion Slot: |
7 slots(ATX) or 14/15 slots(SR) |
| Connector Port (front): |
|
| Indicators: |
LEDs for Power On/Off, HDD Activity |
| Buttons: |
Power ON/OFF Momentary (Pushbutton), System Reset |
| Crossbar: |
|
| Thermal Card: |
|
| Front Door(s): |
Single Door with Keylock |
| Air Filter: |
|
| Dimensions(W x H x D): |
431 x 222 x 557mm (17" x 8.7" x 21.9") |
| Weight: |
22.4 kgs / 49.4 lbs |
| Cu. ft.: |
5.9 |
| Carton Size: |
57.5 x 42.5 x 70.5 (22.6" x 16.7" x 27.8") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
GHI-450.pdf
