| Model: |
GHI-481 |
| Max. Board Size: |
EATX (12" x 13") |
| System Board Type: |
Core i, Core2Duo, Core2Quad, Pentium, Dual Xeon, AMD 64, Dual Opteron, Athlon |
| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard), Beige or Custom |
| Drive Bays: |
1x5.25" & 1xSlim CD-ROM & 1xSlim FDD &14x3.5"Swappable IDE/SATA/SCSI 320/ Multilane SATA/SAS(Optional)Trays & 2 x 3.5"HDD(Optional) |
| Power Supply: |
N+1 Redundant up to 950W ATX P/S (Rear Installation) |
| Cooling Units: |
3x(120mm = 90CFM ea.) Fans & 2x(60mm = 23.5CFM ea.) Fans (Optional) |
| Expansion Slot: |
7 slots |
| Connector Port (front): |
2xUSB Ports |
| Indicators: |
|
| Buttons: |
Power ON/OFF Momentary (Dimple), System Reset, Buzzer Reset |
| Crossbar: |
|
| Thermal Card: |
|
| Front Door(s): |
|
| Air Filter: |
|
| Dimensions(W x H x D): |
483 x 177 x 650mm (19" x 7" x 25.6") |
| Weight: |
28.0 kgs / 61.7 lbs |
| Cu. ft.: |
5.8 |
| Carton Size: |
85.4 x 33.6 x 57.6(33.6" x 13.2" x 22.7") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
| HDD Drive Accessories: |
|
| Slide Rails: |
|
| Chassis Height: |
4U |
|
|
