| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard), Beige or Custom |
| Drive Bays: |
7x 5.25" & 1x 3.5" |
| Power Supply: |
PS/2 Size Single up to 700W or Vertical Redundant up to 550W or Mini Redundant up to 500W ATX P/S (Rear Installation) |
| Cooling Units: |
Hot Swappable 4x(90mm = 51CFM ea.) Fans & 1x (120mm = 108CFM ea.) Fan With Removable Air Filter |
| Expansion Slot: |
7 Slots |
| Connector Port (front): |
|
| Indicators: |
|
| Buttons: |
Power ON/OFF Momentary (Pushbutton),System Reset, Buzzer Reset |
| Crossbar: |
|
| Thermal Card: |
|
| Front Door(s): |
Single Door With Keylock |
| Air Filter: |
Inside Front Door (Washable) |
| Dimensions(W x H x D): |
483 x 356 x 510mm (19" x 16.5" x 18.2") |
| Weight: |
30.5 kgs / 67.3 lbs |
| Cu. ft.: |
7.4 |
| Carton Size: |
60.5 x 50.5 x 68.5(23.8"x19.9"x27") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
GH-800.pdf
