| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard) or Custom |
| Drive Bays: |
1x 5.25" & 1x 3.5" FDD & 1x 3.5" HDD |
| Power Supply: |
1U Single ATX PSU (Rear Installation) Max. Depth 190mm |
| Cooling Units: |
1x (120mm = 90CFM ea.) Fan |
| Expansion Slot: |
8 Slots |
| Connector Port (front): |
2x USB 2.0 Ports (Optional: USB 3.0 Ports) |
| Indicators: |
LEDs for Power ON/OFF, HDD Activity, Fan, Temperature Warning |
| Buttons: |
Power ON/OFF Momentary (Rocker), System Reset, Buzzer Reset |
| Crossbar: |
With Plastic Screw-down Type |
| Thermal Card: |
GHA-CO04 |
| Front Door(s): |
N/A |
| Air Filter: |
Inside Front Panel (Washable) |
| Dimensions(W x H x D): |
307 x 177 x 412 mm(12"x7"x16.2") |
| Weight: |
12.0 kgs / 26.5 lbs |
| Cu. ft.: |
2.9 |
| Carton Size: |
45.5 x 32.4 x 55.8 (17.9" x 12.8" x 22") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
