| Model: |
GHI-359 |
| Max. Board Size: |
ATX (12" x 10.5") |
| System Board Type: |
Core i, Core2Duo, Core2Quad, Pentium, Dual Xeon, AMD 64, Dual Opteron, Athlon |
| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard) or Custom |
| Drive Bays: |
(GHI-359): 3x 5.25" & 6x 3.5" Swappable Trays (GHI-359-1): 5x 5.25" & 4x 3.5" HDD (GHI-359-2): 1x 5.25" & 12x 3.5" Swappable Trays |
| Power Supply: |
2U Single or Redundant ATX P/S (Rear Installation) Max. Depth 300mm |
| Cooling Units: |
3x(40mm = 15.3CFM ea) & 2x (60mm = 23.5CFM ea.) Fan |
| Expansion Slot: |
7 Slots |
| Connector Port (front): |
2x USB Ports |
| Indicators: |
LEDs for Power ON/OFF, HDD Activity, LAN |
| Buttons: |
Power ON/OFF Momentary (Pushbutton), System Reset, Buzzer Reset |
| Crossbar: |
N/A |
| Thermal Card: |
N/A |
| Front Door(s): |
N/A |
| Air Filter: |
N/A |
| Dimensions(W x H x D): |
483 x 133 x 510mm (19" x 5.2" x 20.1") |
| Weight: |
14.9 kgs / 32.9 lbs |
| Cu. ft.: |
4.1 |
| Carton Size: |
67.5 x 29.2 x 59.5 (26.6" x 11.5" x 23.4") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
| HDD Drive Accessories: |
|
| Slide Rails: |
GHA-SL20; GHA-SL26 |
| Chassis Height: |
3U |
|
|
GHI-359.pdf
