| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard) or Custom |
| Drive Bays: |
1x Slim CD-ROM, 1x Slim FDD & 24x 3.5" Hot Swappable & 2x 2.5" HDD |
| Power Supply: |
1U Redundant up to 1650W ATX PSU (Rear Installation) Max. Depth 300mm |
| Cooling Units: |
6x (60mm = 23.5CFM ea.) Fans & 2x (120mm = 90CFM ea.) Fans |
| Expansion Slot: |
7 Slots |
| Connector Port (front): |
2x USB Ports |
| Indicators: |
|
| Buttons: |
Power ON/OFF Momentary (Dimple), System Reset, Buzzer Reset |
| Crossbar: |
|
| Thermal Card: |
|
| Front Door(s): |
Single Door With 2 Thumbscrews (Removable) |
| Air Filter: |
|
| Dimensions(W x H x D): |
483 x 222 x 650mm (19.0" x 8.7" x 25.6") |
| Weight: |
34.5 kgs / 76.1 lbs |
| Cu. ft.: |
6.8 |
| Carton Size: |
85.5 x 37 x 61. (33.7" x 14.6" x 24") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
GHI-584.pdf
