| Board: |
Support 8-slot Passive Backplane |
| Drive Capacity: |
1x 5.25" & 1x 3.5" & 1x 3.5"HDD |
| Power Supply (Optional): |
1U Size Single 250~400W P/S |
| Cooling: |
1x (120mm = 90CFM ea.) Fan |
| Expansion Slots: |
8x Slots |
| Connector Port (Front): |
2x USB Ports |
| Front Door: |
Without Front Door |
| Air Filter: |
Inside Front Panel (Washable) |
| Thermal Management Card: |
GHA-CO03 |
| LCD Size: |
|
| play Color: |
|
| Luminance: |
|
| Indicators: |
LEDs for Power ON/OFF, HDD Activity, Fan, Temperature, LAN |
| Hold Down Bar: |
Flexible Hold Down Bar Designed |
| Switch: |
Power ON/OFF, System Reset, Buzzer Reset |
| Dimensions: |
350x177x411mm(13.8"x7"x16.2") |
| Cuft: |
3.1 |
| GW: |
14 kgs / 33.1 lbs |
| Carton Size: |
48 x 32.4 x 55.8(19.3" x 12.8" x 22") |
| Humidity: |
5% - 95% Non-condensing |
GHB-082-8
