| Board: |
Support 10-slot Passive Backplane |
| Drive Capacity: |
1x 5.25" & 1x 3.5" & 1x 3.5"HDD |
| Power Supply (Optional): |
1U 200~300W P/S |
| Cooling: |
1x (120mm = 90CFM ea.) Fan |
| Expansion Slots: |
10x Slots |
| Connector Port (Front): |
2x USB Ports |
| Front Door: |
|
| Air Filter: |
Inside Front Panel (Washable) |
| Thermal Management Card: |
|
| LCD Size: |
|
| play Color: |
|
| Luminance: |
|
| Indicators: |
LEDs for Power ON/OFF, HDD Activity, LAN |
| Hold Down Bar: |
Flexible Hold Down Bar Designed |
| Switch: |
Power ON/OFF, System Reset |
| Dimensions: |
280 x 237 x 260mm (11" x 9.3" x 10.2") |
| Cuft: |
2.3 |
| GW: |
8.5 kgs / 18.7 lbs |
| Carton Size: |
42.0 x 38 x 40(16.5" x 15" x 15.8") |
| Humidity: |
5% - 95% Non-condensing |
GHB-083-10
