| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard) or Custom |
| Drive Bays: |
4x 5.25"Open Bay & 2x 3.5"HDD Bay & 1x 3.5"Open Bay |
| Power Supply: |
2U Single or Redundant ATX PSU (Rear Installation) Max. Depth 265mm |
| Cooling Units: |
4x (80mm = 42.5CFM ea.) |
| Expansion Slot: |
GHI-220(With 3-horizontal slots back panel); GHI-220V(With 7 vertical low-profile slots back panel) |
| Connector Port (front): |
2 x USB Ports |
| Indicators: |
LEDs for On/Off; HDD Activity, 2x LAN Activity |
| Buttons: |
Power ON/OFF Momentary (Dimple), System Reset |
| Crossbar: |
1x |
| Thermal Card: |
N/A |
| Front Door(s): |
Single Door With 2 Thumbscrew and Removeable Door |
| Air Filter: |
None |
| Dimensions(W x H x D): |
483 x 88 x 570mm (19" x 3.5" x 22.4") |
| Weight: |
13.4 kgs / 29.5 lbs |
| Cu. ft.: |
2.9 |
| Carton Size: |
56.2 x 20.3 x 71.3 (22.1" x 8" x 28.1") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
