Input / Output Ratings

Model 　Input(AC) 　Output(DC) Voltage Frequency Current Watt Load +5V +3.3V +12V -5V -12V 5Vsb FLEX-0130D 100-240V 47-63Hz 8A-4A 250W Max. 12A 22A 22A N/A 0.3A 2.5A Min. 0A 0A 0A N/A 0A 0A Max. Comb. └ 110W ┘ 250W N/A N/A N/A   Note 1: Maximum continuous total DC output power should not exceed 250W.

Electrical Specification

Regulation, Ripple & Noise
Item / Output		+5V	+3.3V	+12V	-5V	-12V	5Vsb
Load Regulation		±5%	±5%	±5%	N/A	±10%	±5%
Cross Requlation
Line Regulation
Ripple & Noise		50mV	50mV	120mV	N/A	120mV	50mV
